Stop Wrestling with RF Design. Start Building. Faster.
Quantic X-Microwave’s Layout Tool is a powerful, interactive design environment enabling part selection and layout of signal chains using X-MWblocks.
This tool aims to simplify the design process, whether for prototype plates or standard connectorized housings. At its core, the Layout Tool provides a visual environment for users to construct their designs, allowing users to select and place X-MWblocks from an extensive library onto a virtual canvas.
Key Features include:
- Expanded Component Library (6000+ X-MWblocks):
- This extensive library ensures users have access to a wide range of components, reducing the need for manual part specification and enabling more complex designs.
- Regular updates to the library ensure access to the latest X-MWblocks.
- Redesigned User Interface:
- The updated interface prioritizes ease of use, aiming to reduce the learning curve and improve overall design efficiency.
- This allows designers to focus on the design itself, rather than navigating complex software.
- Automated Wall Algorithm:
- This feature automates the creation of arbitrary shaped channelized enclosures, particularly relevant during the prototyping phase.
- This reduces the time and effort required to define physical boundaries and ensures accurate enclosure design.
- Export Capabilities (CSV):
- Users can export a complete list of components and accessories to a CSV file.
- This export function facilitates:
- Accurate Bill of Materials (BOM) creation.
- Simplified documentation.
- Efficient quote requests
Access to the Layout Tool requires user registration. Users can also access the previous version of the Layout Tool, soon to be obsolete, here.
